Product Details
| 제품 이름: | 합금 강철 플레이트 | 표준: | AISI, ASTM, BS, DIN, JIS |
|---|---|---|---|
| 신청: | 배 판 | 기술: | 냉각 압연하는/열간압연 |
| 강조하다 |
압력 용기 판,배 강철 플레이트 |
||
Product Description
Q235 Q345 B C D E는 6 - 80mm 냉각 압연하고/열간압연 합금 강철 플레이트 간격
Q345B/C/D/E
1)기준: GB
2)간격: 6-80mm
3)폭: 1600-3200mm
4)길이: 6000-14000mm
5)) 고품질 저가
화학 성분 (WT %)
| C | Si | Mn | P | S | V | Nb | 알루미늄 | 티타늄 | |
| Q345A | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.045 | ≤0.045 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345B | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.040 | ≤0.040 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345C | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.035 | ≤0.035 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345D | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.030 | ≤0.030 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345E | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.025 | ≤0.025 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
기계적인 Properities
| 간격 | 온도 (°c)를 시험하십시오 | 신장 (%) | 보증 응력 (Mpa) | 장력 strenth (Mpa) | |
| Q345A | ≤16 | - | 21 | 345 | 470-630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470-630 |
| Q345C | 16-35 | 0 | 22 | ≥325 | 470-630 |
| Q345D | 35-50 | -20 | 22 | ≥295 | 470-630 |
| Q345E | 50-100 | -40 | 22 | ≥275 | 470-630 |
우리의 제품
| 제품 시리즈 | 행정상 기준 | 급료 | 종류 | 간격 (mm) |
납품 국가 |
| 낮 합금 구조 강철 | GB/T 1591-2008GB/T 3274-2007 | Q345 | A, B | 6~150 | AR |
| C, D | 6~150 | 크롬 | |||
| E | 6~150 | TMCP | |||
| Q390 | A, B, C, D, E | 6~150 | 크롬 | ||
| Q420 | 6~150 | TMCP | |||
| Q500 | 6~100 | TMCP | |||
| Q550 | 6~100 | ||||
| Q620 | 6~80 | ||||
| Q690 | 6~80 | ||||
| GB/T 28410-2012 | Q235FT | B, C, D, E | 5~150 | AR의 크롬 | |
| Q275FT | C, D, E, F | 5~150 | AR의 크롬 | ||
| Q345FT | C, D, E, F | 5~150 | AR의 크롬 | ||
| Q420FT | C, D, E, F | 5~150 | AR의 크롬 | ||
| Q460FT | C, D, E, F | 5~150 | AR의 크롬 | ||
| EN 10025-4:2004 | S275M/ML | - | 6~60 | TMCP | |
| S355M/ML | |||||
| S420M/ML | |||||
| S460M/ML | |||||
| JIS G3106: 2008년 |
SM400 SM490 |
A, B, C | 6~150 | AR | |
| A, B, C | 6~150 | 크롬 | |||
| YA, YB | |||||
| SM520 | B, C | 6~80 | TMCP | ||
| SM570 | 6~80 | ||||
| ASTM A572/A572M-12 | Gr42 | - | 6~150 | AR | |
| Gr50 | - | 6~100 | 크롬 | ||
| Gr55 | - | 6~100 | |||
| Gr60 | - | 6~80 |
TMCP |
